Hydrology & hydraulics software for engineers

A complete hydrology & hydraulics studio, run by you or your AI agent.

Delta Hydro Studio links catchment, rainfall, runoff and hydraulics into one workflow. Work in the browser, or connect your own AI agent: it runs the calculations on the same engines, and you review the result.

-33.9321, 18.8602 · WGS84

Bring your own agent · MCP server in beta

Your agent runs the calculations. You review the engineering.

Connect the agent you already use (Claude, ChatGPT, Cursor) to Delta Hydro Studio over MCP. Ask it for a design flood or a culvert and it works down the chain on Studio's engines: catchment, rainfall, peak flow, hydraulics. Every result lands in your project as a record you can open on the map, check and export.

Your AI agent
Claude · ChatGPT · Cursor · any MCP client
FARM ROAD CATCHMENT 4.2 km² FLOW PATH Tc 0.62 h CULVERT · HDS-5 3.6 × 2.4 m box · HW/D 1.07 500 m
Studio · project map
Rainfall · mm/h
1:10 33.3
1:50 51.7
1:100 62.0
Rational · Q 1:50
21.1m³/s
Culvert
3.6 × 2.4 m box

Size a box culvert for the 1:50 flood at the crossing I have selected in QGIS. Tailwater 0.9 m.

  1. QGIS Read the selected crossing
    Road 103.20 m · inverts 100.00 / 99.76 m · 24 m long
  2. Studio delineate_watershed
    Catchment 4.2 km²
  3. Studio compute_time_of_concentration
    Tc 0.62 h
  4. Studio compute_design_rainfall
    1:50 · 51.7 mm/h
  5. Studio run_rational
    Q 1:50 = 21.1 m³/s
  6. Studio size_culvert
    3.6 × 2.4 m box · HW/D 1.07

Five records are saved in the project. Two things are yours to decide: the runoff coefficient, which I took as 0.35 from the published table, and outlet protection, because the barrel discharges at 6.1 m/s.

Ready for your review
Open in Studio Word report
An example session. The values are the ones Studio's engines return for these inputs; the map is a drawing, to scale.
  • Nothing to type in

    The agent passes the inputs to the engine itself, including what it reads from your other tools: a point from QGIS, levels from a spreadsheet. No forms, and no copying values from one program to the next.

  • Engines do the arithmetic

    Every number comes from the engines behind the Studio calculators: FHWA HDS-5 for a culvert, the Rational method or TR-55 for a peak. The language model never computes a result.

  • A record to check and sign

    Each run is saved to your project with its inputs, marked as agent work in the audit trail, and opens in Studio with charts, tables and Word and Excel exports.

One agent, all your tools

Bring your own agent. It brings the rest of your tools.

Studio is built for the agent you already use, not for a chatbot of its own. Claude, ChatGPT or Cursor is connected to more of your work than an assistant inside our app could be: your GIS, your files, your email. Add Studio to its connectors and it carries the data across. It reads a crossing in QGIS, runs the hydrology and hydraulics in Studio, and writes the result where you need it.

Its other connectors
  • QGIS

    Layers, selected features and survey points, through a QGIS MCP server.

  • Files and spreadsheets

    Level schedules, survey exports and earlier reports.

  • Documents and email

    The brief, the client’s questions, the memo the results go into.

Your agent
Claude · ChatGPT · Cursor
Delta Hydro Studio
MCP server
  • 80 calculation tools
  • Records saved to your project
  • Word and Excel reports
QGIS Studio

From a layer of crossings to a flood study per site

The agent reads the outlets from your QGIS layer and submits them to Studio as one batch, quoted before it runs. Flood studies cover South African sites.

Spreadsheet Studio

From a level schedule to sized culverts

It takes the road and invert levels from your spreadsheet and sizes each crossing on the HDS-5 engine, with a saved record for every culvert.

Studio Your report

From saved records to the design memo

It reads the results back from Studio and drafts the memo in your own document tool, with a link to each record.

Where engineering software is going

On its own, ChatGPT guesses. Connected to Studio, it calculates.

Design software has always been worked by hand: one form, one value at a time. Agents change who does that work. An AI model can talk about hydraulics, but it cannot be trusted with the arithmetic, and it leaves nothing behind for a reviewer. An agent needs engines it can call, records it can leave and limits it cannot argue its way past. Studio is built for that.

Without engines

ChatGPT or Claude on its own, asked to design a culvert

  • The number comes out of a language model. It can be wrong and still read as right.
  • No method is named and no inputs are kept, so there is nothing to check it against.
  • Ask the same question twice and you can get two answers.
  • The answer stays in a chat window. You retype it into your design.
With engines

The same agent, connected to Delta Hydro Studio

  • The agent calls the engine: FHWA HDS-5 for the culvert, the Rational method for the peak. The model supplies inputs and reads results.
  • Every input and result is saved as a record in your project.
  • The same inputs give the same result, every time.
  • The record opens in Studio with charts, intermediate tables and a Word and Excel report.
Automation

The data entry goes away

A flood study is a long chain of forms: delineate, read off the rainfall, fill in each method, size the structure, copy it all into a report. An agent works through the same steps in the same order, and stops at each decision that is yours.

Scale

Two hundred sites, one instruction

Hand the agent a list of crossings. One submission runs a flood study for up to 200 outlets, each with the methods its own catchment allows, and one table compares the sites. Flood studies cover South African sites.

Review

The engineer becomes the reviewer

Your hours go to checking catchments, questioning assumptions and choosing the design flood. The agent recommends. A ruling is recorded only when you state it, under your name.

Free calculators · no sign-up

Run the numbers now

The same engines as Delta Hydro Studio, in SI or US customary units, each with a method guide and worked example. Saving and exports open with Studio accounts soon; join the waiting list to be told first.

Runoff

Rational method calculator

Peak flow from Q = CiA, with a runoff coefficient lookup and an area-weighted C for mixed land use.

Open calculator
Runoff

TR-55 calculator

Runoff depth and peak discharge by the NRCS graphical method, with a curve number lookup and area-weighted CN.

Open calculator
Runoff

Unit hydrograph calculator

SCS, Snyder, Clark, gamma and triangular unit hydrographs, with the ordinates and the runoff volume.

Open calculator
Frequency & data

Flood frequency analysis

Fit LP3, GEV and Gumbel to annual maxima by L-moments or moments, with outlier and trend tests.

Open calculator
Rainfall

Design storm generator

Hyetographs from SCS Type I to III, Huff, Chicago and alternating block patterns, from a depth or an IDF curve.

Open calculator
Catchment

Time of concentration calculator

Kirpich, NRCS lag, FAA, Kerby and USBR side by side, or the sheet, shallow and channel flow segments.

Open calculator
Hydraulics

Manning's equation calculator

Normal and critical depth, velocity and Froude number for trapezoidal, rectangular, triangular and pipe sections.

Open calculator
Hydraulics

Channel lining calculator

Permissible shear check by FHWA HEC-15 for riprap, gabions, grass and erosion control mats, with the normal depth.

Open calculator
Hydraulics

Culvert calculator

Headwater under inlet and outlet control by FHWA HDS-5, with the performance curve and road overtopping.

Open calculator
Hydraulics

Riprap sizing calculator

Stone size, FHWA gradation class and layer thickness for banks, piers, abutments and culvert outlets.

Open calculator
Hydraulics

Weir flow calculator

Head or discharge for broad-crested, sharp-crested, V-notch, Cipolletti and ogee weirs, with the rating curve.

Open calculator
Hydraulics

Gradually varied flow

Backwater and drawdown profiles by the direct or standard step method, classified M1 to A3.

Open calculator
Why Studio

Built for professional practice

Everything in one cloud workspace — not a patchwork of spreadsheets and single-user GIS scripts.

A complete H&H studio

Catchment, rainfall, runoff, and hydraulics tools in one place — plus frequency analysis and safety workflows when you need them.

Cloud-native — no installs

Run professional hydrology and hydraulics in the browser. Share consistent inputs and outputs across your team.

Design-grade exports

Word, Excel, and GIS outputs structured for deliverables — no copy-paste report assembly.

Tool suite

Every tool has its own page

Scroll the full lineup — every tile links to a dedicated landing page.

View tools hub
Runoff

Rational Method Calculator

Peak discharge from the rational formula Q = CiA with runoff coefficient guidance, design rainfall integration, and multi-return-period tables.

Runoff

TR-55 Peak Discharge Calculator

Graphical peak discharge method following USDA NRCS TR-55 for estimating post-development flows and comparing pre/post scenarios.

Runoff

Hydrograph Generator

Build synthetic unit and design hydrographs including SCS dimensionless UH, triangular hydrographs, and custom peak/volume targets.

Frequency & data

Flood Frequency Analysis

Fit and compare frequency distributions (LP3, GEV, Gumbel, Normal, and more) using method of moments, L-moments, and MLE with best-fit ranking.

Frequency & data · South Africa

Index Flood Method

Regional frequency analysis using the index-flood approach — combine site and regional information for robust estimates where data is sparse.

Safety · South Africa

PMP Calculator

Probable maximum precipitation estimates for dam safety and extreme-event design, including HRU-style classification workflows.

Safety · South Africa

RMF Calculator

Regional maximum flood estimates for extreme-event checks using envelope-style approaches applied in South African practice.

Workflows · South Africa

Design Flood Estimation

Map-led catchment studies: delineate a catchment, run multiple flood estimation methods, and export design-grade Word, Excel, and GIS outputs.

Frequency & data · South Africa

QRT Calculator

Quantile regression techniques for flood estimation at ungauged sites using catchment attributes and regionalized predictors.

Rainfall

Design Rainfall

Depth–duration–frequency (DDF) estimates and IDF-style curves from regional models and international datasets, plus user data import where needed.

Rainfall

Daily Rainfall Statistics

Explore and quality-check historical daily rainfall records for South African stations and selected international sources.

Rainfall

Design Storm Generator

Synthetic design hyetographs including alternating block, SCS/NRCS distributions, Huff-style partitions, and large regional pattern libraries.

Rainfall

ARF Calculator

Areal reduction factors for South African design rainfall using published regional guidance, catchment polygons, and depth–duration context.

Catchment

Tc Calculator

Time of concentration by Kirpich, NRCS lag, FAA, Kerby and the USBR equation side by side, or by the FHWA sheet, shallow and channel flow segments.

Rainfall · South Africa

PRM Calculator

The Probabilistic Rational Method of Calitz & Smithers (2020): regionally calibrated runoff coefficients for design floods at ungauged South African sites.

Hydraulics

Channel Analysis

Open-channel hydraulics with Manning's equation: trapezoidal, rectangular, circular, and custom sections with normal/critical depth and rating curves.

Hydraulics

Channel Lining

Stable lining selection using tractive-force concepts consistent with HEC-15 for vegetated, riprap, and articulated-block systems.

Hydraulics

Culvert Designer

Culvert hydraulics with inlet and outlet control checks, headwater–discharge performance curves, and multi-barrel configurations — plus a sizing assistant that ranks commercial barrel sizes against your headwater, velocity and cover constraints.

Hydraulics

Detention Basin Designer

Stormwater detention routing with Modified Puls level-pool routing, multi-stage outlets, and target release workflows.

Hydraulics

Riprap Design

Size protective stone for channel banks, bridge piers and abutments, spurs, culvert outlet aprons, open-bottom culverts and wave-exposed slopes — FHWA HEC-23 and HEC-14, matched to standard FHWA gradation classes.

Hydraulics

Weir Analysis

Head–discharge relationships for broad- and sharp-crested weirs with submergence checks and practical sizing feedback.

Hydraulics

GVF Profiles

Gradually varied flow profiles using the direct step method with M1, M2, S1, S2 classification support along prismatic channels.

Catchment

Watershed Delineation

Delineate catchments from MERIT-Hydro and related DEM sources with stream ordering, longest flowpath extraction, and GIS export.

Catchment

Watercourse Profile

Longitudinal watercourse profiles with elevation sampling along streams — document slopes and falls for hydraulic and geomorph studies.

Frequency & data

Stream Gauge Finder

Locate streamflow gauges near your study site in South Africa (DWS), the United States (USGS) or Australia (BoM), filter by record length and status, and send annual peaks to flood frequency analysis.

Safety · South Africa

Dam Safety Evaluation

Dam safety study workflows including classification context, extreme rainfall inputs, and routing concepts aligned with South African dam practice.

How it works

From map click to Word report

Four steps your reviewers can follow — with the audit trail they expect.

Step 01

Define the site context

Drop a pin, trace a reach, or upload a boundary — the map stays connected across tools.

Step 02

Run the linked steps

Catchment → rainfall → runoff → hydraulics, with guided inputs and repeatable defaults.

Step 03

QA with transparency

Charts, intermediate tables, and methodology notes stay visible for peer review.

Step 04

Export deliverables

Generate structured tables and exports your CAD/GIS and report packs can consume.

Why teams leave spreadsheets behind

The comparison pages cover review trails, collaboration, standards coverage and where desktop GIS still wins, so you can choose the right tool for each job.

Explore comparisons

Simple credit-based pricing

Stream (free), River (Pro), and Delta (Team) — with global checkout through Paddle.

See full pricing

Custom engineering & integrations

Need bespoke software, QGIS plugins, H&H stack integrations, or dashboards for your agency? We build alongside Delta Hydro Studio. For traditional consulting studies, our practice lives at deltahydro.co.za.

View services
FAQ

Frequently asked questions

Can my own AI agent run calculations in Delta Hydro Studio?
Yes. Studio has an MCP server, in beta, with 80 tools. Connect Claude, ChatGPT, Cursor or another MCP client to your account and the agent can delineate catchments, derive design rainfall, run peak-flow methods and size culverts on the same engines as the calculators. Each result is saved to your project for you to review. How agents use Studio.
How is that different from asking ChatGPT to design a culvert?
On its own, ChatGPT (or any AI model) produces the number itself, with no method or inputs on record. Connect the same agent to Studio and it passes the inputs to the calculation engine (FHWA HDS-5 for a culvert) and reads the result back. The model never does the arithmetic, the same inputs always give the same result, and the saved record shows every input to the reviewer.
Is Delta Hydro Studio only for South Africa?
No. The calculators and most workflows work anywhere in the world. Design Flood Estimation and the South African regional methods (SDF, RMF, QRT, the Index Flood and PRM methods, among others) apply to South African sites only, and are marked South Africa on their tool pages.
Do I install desktop GIS or HEC-RAS to use it?
No local installs are required for the core workflows. You work in the browser and export to the formats your CAD/GIS stack already accepts.
What does “Start free” include?
You can register on the Stream plan to explore tools with credits. Several hydraulic and delineation tools remain accessible without a paid subscription.
Where is documentation?
The knowledge base at docs.deltahydro.tech covers every tool: method, equations, inputs, limitations and worked examples. Book a demo if you would like a guided tour.
How does billing work?
Subscriptions and credit top-ups are handled inside the studio via Paddle. See the pricing page for tiers in multiple currencies.
Can teams share credits?
Yes. Team plans use a shared credit pool with admin controls — ideal for practices that run many studies per month.
Talk to an engineer

Book a 30-minute demo

Prefer to see the product live before you sign up? Grab a slot — we will focus on flood, hydraulics, or rainfall workflows based on what you select in the booking form.

Start free today

No credit card required to explore. Enterprise rollout? Use the calendar above or email sales.
